Simpson Strong-Tie MIU Medium Face-Mount 11-7/8 in. Double I-Joist Hanger

In stock
SKU
11DF360


The MIU hanger is designed for commercial, high-load and double I-joist applications without requiring web stiffeners. The MIU features positive-angle nailing (PAN) which minimizes splitting of the flanges while permitting time-saving nailing from a better angle. This face-mount hanger features speed prongs to temporarily position and secure the connector for easier and faster installation. Width 4-3/4 in. Height 9-1/16 in. Depth 2-1/2 in.
$27.00
each
Select a branch
173 Available in stock
Delivery
Available
  • Extra optional triangle holes for additional load
  • Models will normally accommodate a skew of up to 5°
  • MIU-series hangers are tested, load rated and code compliant
More Information
TypeFace-Mount Hangers
Size11⅞ in.
Gauge16 ga.
BrandSimpson Strong Tie
StyleDouble
FinishGalvanized
MaterialSteel
Manufacturer CodeMIU4.75/11
Fasteners Needed Face: (20) 0.162 x 3-1/2 in. Joist: 0.148 x1-1/2 in.
